High Technology Integration Oxidation Blower All In One For Steel Mill

High Technology Integration All in One Oxidation Blower for Steel Mill

Product Introduction

The specification sheets detail the blower's model number, cylinder bore, rotational speed (RPM), discharge pressure, airflow capacity, and power requirements.

The air capacity in the tables is indicated in the standard suction state.The standard suction state herein mentioned is defined as the condition at 20℃ temperature, 1.0332Kgf/cm² (101.3KPa) absolute pressure and 65% relative humidity.

The reference air capacity (temperature 0℃ and 1.0332kgf/cm² (101.3kpa) absolute pressure) is generally indicated in Nm³/min.

However, it may be converted into the standard air capacity by the following equation, if the suction pressure is equal.

Qs = QNx1.0732

Where, Qs: standard air capacity (m³/min); and

QN: reference air capacity (m³/min).

The following equation converts discharge air capacity to standard air capacity values.

Qs = Qdx (1.0332+Pd)/ 1.0332x(273+Ts)/(273 + Td)

Where, Qd : discharge air capacity, in m³/min;

Pd : discharge pressure, in Kgf/cm²,

Ts : suction temperature, in ℃,

Td : discharge temperature, in ℃.

The performance table provides matching model, bore, RPM, and power requirements for the computed air capacity and discharge pressure.

Sl Units Conversion Table ( Sl Units in Heavy Lines )

Product Specification

Product Show

Delivery

Why Select Worldwide Express for Your Deliveries?

At Worldwide Express, we collaborate with top logistics providers to ensure your shipments are delivered swiftly, securely, and reliably.   Whether you require air freight, ground transportation, or expedited services, we offer flexible solutions customized to your needs.

Our EHS standards guarantee responsible handling of your products, reducing risks and environmental impact.  With worldwide coverage and live tracking, you can rely on us for smooth logistics operations—anywhere, anytime.
Your Delivery, Your Terms!

• Fast & Reliable – ensures on-time delivery
• Global Network – Ship to over 220 countries
• Safety Compliance – EHS-certified handling
• Custom Solutions – Choose air, sea, or land transport

• Get requirements to match products
• Quotation
• Receive payment
• Production
• Packing with wooden cases
• Delivery
• Feedback

FAQ

Q1: What factors will you need to match the products?

Pressure & Flow Volume

Q2: What is the production time?

Normally one week after receiving your payment.

Q3: What is your minimum order quantity?

MOQ 1 set.

Q4: Are you a manufacturer?

Yes.

Q5: Which delivery methods can you support?

By air, sea, land, rail, express like DHL, UPS, FEDEX.
