50A - 300A Bore Air Knife Blowers For Iron And Steel Industry Electroplating Plant

Industrial Air Knife Blower for Iron and Steel Industry Electroplating Plant

Product Introduction

Performance charts list blower specifications: model, bore, RPM, output pressure, air volume, and required power.

The air capacity in the tables is indicated in the standard suction state.The standard suction state herein mentioned is defined as the condition at 20℃ temperature, 1.0332Kgf/cm² (101.3KPa) absolute pressure and 65% relative humidity.

The reference air capacity (temperature 0℃ and 1.0332kgf/cm² (101.3kpa) absolute pressure) is generally indicated in Nm³/min.

However, it may be converted into the standard air capacity by the following equation, if the suction pressure is equal.

Qs = QNx1.0732

Where, Qs: standard air capacity (m³/min); and

QN: reference air capacity (m³/min).

Standard air capacity can be derived from discharge air capacity using the conversion formula below.

Qs = Qdx (1.0332+Pd)/ 1.0332x(273+Ts)/(273 + Td)

Where, Qd : discharge air capacity, in m³/min;

Pd : discharge pressure, in Kgf/cm²,

Ts : suction temperature, in ℃,

Td : discharge temperature, in ℃.

The performance table provides matching model, bore, RPM, and power requirements for the computed air capacity and discharge pressure.

Sl Units Conversion Table ( Sl Units in Heavy Lines )

Product Specification

Product Show

Our History

Our company was founded in 2007, in the next 3 years we had gone to Korea to learn the high technology to develop our products. In 2013, our products have been widely used in Chinese market to save cost, increase efficiency, and decrease noise. To match the market all over the world, we have developed the high pressure products which are more than 4000KPA with more than 30 patent technologies from 2020. Nowadays, according to products updates in quality and convenience, our products are increasingly accepted by more and more customers.

Our Service

• Professional Team
• Reliable Technology
• 24 Hours Service

Delivery

Why Select Worldwide Express for Your Deliveries?
At Worldwide Express, we collaborate with top logistics providers to ensure your shipments are delivered swiftly, securely, and reliably.  Whether you require air freight, ground transportation, or expedited services, we offer flexible solutions customized to your needs.
Our EHS standards ensure that your products are handled responsibly, minimizing risks and environmental impact.  With global coverage and real-time tracking, you can trust us for seamless logistics—anywhere, anytime.
Your Delivery, Your Terms!

• Fast & Reliable – ensures on-time delivery
• Global Network – Ship to over 220 countries
• Safety Compliance – EHS-certified handling
• Custom Solutions – Choose air, sea, or land transport

FAQ

Q1: What factors will you need to match the products?

Pressure & Flow Volume

Q2: What is the production time?

Normally one week after receiving your payment.

Q3: What is your minimum order quantity?

MOQ 1 set.

Q4: Are you a manufacturer?

Yes.

Q5: Which delivery methods can you support?

By air, sea, land, rail, express like DHL, UPS, FEDEX.
